Product Specifications
| Cutter Diameter (Decimal Inch) | 0.2850" |
| Drill Diameter (Decimal Inch) | 0.3141" |
| Minor Diameter (Decimal Inch) | 0.2205" |
| Length of Cut (Decimal Inch) | 0.9102" |
| Drill Length (Inch) | 1/16" |
| Drill Length (Decimal Inch) | 0.0625" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.0000" |
| End Length (Decimal Inch) | 0.1607" |
| Chamfer Length (Decimal Inch) | 0.0468" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Point Angle | 130 Degree |
| Secondary Point Angle | 90 Degree |
| Number of Flutes | 3 |
| LOC Multiple | 3x |
| Size (Inch) | 3/8-16 |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | TiB2 |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
