Product Specifications
| Cutter Diameter (Decimal Inch) | 0.1800" |
| Drill Diameter (Decimal Inch) | 0.2013" |
| Minor Diameter (Decimal Inch) | 0.1224" |
| Length of Cut (Decimal Inch) | 0.6345" |
| Drill Length (Decimal Inch) | 0.0500" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| End Length (Decimal Inch) | 0.1180" |
| Chamfer Length (Decimal Inch) | 0.0394" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Point Angle | 130 Degree |
| Secondary Point Angle | 90 Degree |
| Number of Flutes | 3 |
| LOC Multiple | 3x |
| Size (Inch) | 1/4-20 |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | Uncoated |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
