Features
- Designed for threading hardened steels 48-68Rc
- Single thread form designed to mill common pitch sizes
- Cuts internal and external 60 Degree metric threads
- Tip of included angle ground to a flat for increased wear resistance
- Large rigid core diameter and eccentric relief for improved strength
- Mills left hand and right hand threads
- h6 shank tolerance for high precision tool holders
- Latest generation AlTiN Nano coating offers superior hardness and heat resistance
- Select carbide grade for improved edge retention
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 724224-C6 |
| Cutter Diameter (mm) | 2.300mm |
| Shank Diameter (mm) | 3.000mm |
| Neck Diameter (mm) | 1.541mm |
| Length of Cut (mm) | 0.531mm |
| Maximum Depth of Thread (mm) | 9.500mm |
| Overall Length (mm) | 38.000mm |
| Tip Flat (mm) | 0.050mm |
| Size | M3 |
| Angle per Side | 30 Degree |
| Included Angle | 60 Degree |
| Number of Flutes | 4 |
| Reach Multiple | (7x) |
| Coating | C6 |
| Profile | Single Form |
