Product Specifications
| Manufacturer Part Number | 695131 |
| Diameter (Inch) | 1/32" |
| Diameter (Decimal Inch) | 0.031" |
| Neck Diameter (Decimal Inch) | 0.030" |
| Length of Cut (Inch) | 5/32" |
| Length of Cut (Decimal Inch) | 0.156" |
| Overall Reach (Inch) | 3/8" |
| Overall Reach (Decimal Inch) | 0.375" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.500" |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.125" |
| Number of Flutes | 4 |
| Material | Carbide |
| Coating | CVD Diamond |
| Product Type | Square End Mill |
