Product Specifications
| Head Diameter (Decimal Inch) | 0.1650" |
| Neck Diameter (Decimal Inch) | 0.1210" |
| Chamfer Center Diameter (Decimal Inch) | 0.1469" |
| Length Of Cut (Decimal Inch) | 0.0191" |
| Neck Length (Decimal Inch) | 0.7500" |
| Neck Length (Inch) | 3/4" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Chamfer Center Length (Decimal Inch) | 0.0695" |
| End Length (Decimal Inch) | 0.0600" |
| Angle Per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 6 |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (Inch) | 3/16" |
| Metric | No |
| Coating | Uncoated |
