Features
- Designed for deep cavity profiling
- 2 Degree tapered neck design minimizes deflection and maximizes wall clearance
- Length of cut = 1½ x diameter
- Neck behind length of cut is reduced for 1x diameter
- h6 shank tolerance for high precision tool holders
- Center cutting
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 18909 |
| Cutter Diameter (Inch) | 0.1410" |
| Neck Diameter (Inch) | 0.2280" |
| Minor Diameter (Inch) | 0.1310" |
| Length of Cut (Inch) | 0.2109" |
| Tapered Reach (Inch) | 1.7500" (1-3/4) |
| Overall Reach (Inch) | 2.0000" (2) |
| Overall Length (Inch) | 4.0000" (4) |
| Neck Length (Inch) | 0.3515" |
| Shank Diameter (Inch) | 0.2500" (1/4) |
| Neck Angle | 4 Degree |
| Number of Flutes | 2 |
| LOC Multiple | (1.5x) |
| Coating | Uncoated |
| Profile | Ball |
