Features:
- Rekord B-Steel-L design is typically for through hole applications in long-chipping materials
- The spiral point ensures optimum chip removal in the feed direction
- TIN coated for additional heat and wear resistance
- DIN/DIN standard dimensions for overall length and shank size
Product Specifications
| Manufacturer Part Number | C0208400.0329 |
| Thread Size | M 14x1 |
| Thread Diameter Size | M 14 |
| Thread Standard | MF |
| Thread Pitch (mm) | 1.00mm |
| Tap Square (mm) | 9.00mm |
| Thread Length (mm) | 18.00mm |
| Tap Chamfer | 4-5 P |
| Tap Chamfer Form | B |
| Dimensional Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Flute Direction | Straight |
| Group Length | DIN Length |
| Coolant Supply Property | External |
| Coolant Fed | No |
| Cutting Edge Material | HSSE |
| Coating | TiN |
| Tool Type | Rekord B-Steel-L |
| Application | Spiral Point Taps |
| Product Type | Spiral Point Tap |
