Product Specifications
| Chamfer | 2-3 P |
| Chamfer Form | C |
| Pitch | 2.5 |
| Size | STI-M 20-2.5 |
| Thread Limit | 6H mod |
| Thread Standard | LKM |
| Coolant Fed | No |
| Coating/Finish | NT |
| Material | HSSE |
| Shank Diameter (mm) | 16 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 140 mm |
| Flute Direction | Straight |
