Features:
- Designed for trochoidal milling strategies. Reduced radial cuts with longer depth of cuts
- Allows for higher feed rates. Chip breaker flute design helps control chip size and improve performance
Product Specifications
| Chamfer Form | |
| Size | 5/8" |
| Applicable Material | Titanium, Stainless Steel, Nickel Alloys |
| Application | Finisher |
| Type | Trochoidal |
| Length Group | 3 x D |
| Coolant Fed | Axial |
| Coating/Finish | TIN/TIALN |
| Material | Carbide |
| Number of Flutes | 5 |
| Helix Angle (Degrees) | 38/42 Degree |
| Shank Diameter (mm) | 5/8" |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (mm) | 4-1/4" |
| Flute Length (mm) | 1-7/8" |
| Flute Direction | Right Hand |
| Corner Radius | 0.090" |
