Revolving Handles-Square Design
Modern square-design handle made of stainless steel, with a polished finish. Revolving Handles have an internal bearing that allows the handle to remain fixed in your hand, for firm gripping while turning a Hand Wheel or crank.
Application Information
Revolving Handles can be used to make custom crank handles
Material
| Material | Heat Treat | Finish | DFARS | RoHS |
| 300-Series Stainless Steel | Yes | Yes | Yes | Yes |
Parts Specification
| Handle Size | A (Inch) | B (Inch) | C Thread (Inch) | D Diameter (Inch) | E Diameter (Inch) | F (Inch) | G (Inch) |
| Size 1 | 1-1/2" | 9/32" | 1/4-20" | 5/8" | 15/32" | 5/16" | 0.20" |
